Structure:
Inner tube :SBR FDA approved material
Reinforcement: high strength synthetic fabric (including spiral steel wire)
Cover: wear-resistant, weather-resistant, ozone resistant synthetic rubber
Operating temperature:
To 40 ° C to + 100 ° C,
Application: for pumping and draining food, such as water, juice, beverage, milk
Market: Food processing, canning truck, dairy processing, milk processing
For joint assembly methods and other joint suggestions, please contact our sales representative.
Product parameters:
|
Item NO |
I.D mm |
O.D mm |
Maximum working pressure(bar) |
Burst pressure (bar) |
Bend Radius (mm) |
Vacuum (kPa) |
Weight (Kg/m) |
Length (m) |
|
LKE-652-019 |
19 |
30 |
10.5 |
31 |
60 |
94.8 |
0.63 |
40、60 |
|
LKE-652-025 |
25 |
37 |
10.5 |
31 |
75 |
94.8 |
0.81 |
40、60 |
|
LKE-652-031 |
31 |
44 |
10.5 |
31 |
95 |
94.8 |
1.06 |
40、60 |
|
LKE-652-038 |
38 |
51 |
10.5 |
31 |
110 |
94.8 |
1.34 |
40、60 |
|
LKE-652-045 |
45 |
57.5 |
10.5 |
31 |
130 |
94.8 |
1.53 |
40、60 |
|
LKE-652-051 |
51 |
66 |
10.5 |
31 |
150 |
94.8 |
1.87 |
40、60 |
|
LKE-652-060 |
60 |
77.5 |
10.5 |
31 |
280 |
94.8 |
2.29 |
40、60 |
|
LKE-652-080 |
80 |
92 |
10.5 |
31 |
340 |
94.8 |
2.98 |
40、60 |
|
LKE-652-102 |
102 |
117.5 |
10.5 |
31 |
450 |
94.8 |
3.94 |
40、60 |
